Features and Specifications
- Sealed, Pressure Compensating Online Emitter Sealed and compact emitter offers ease of installation.
- Precision Pressure Compensation Precision moulded liquid silicone rubber diaphragm ensures pressure compensation, uniform water application and long lasting high quality performance
- Extended Barbed Outlet Barbed extended outlet suitable for extension tube of 3.2 mm ID (1/8″ ID)
- Color Coded Color coded emitter facilitates easy identification of flow rate
- Unique Self Cleaning Mechanism Unique self cleaning design, flow path expands in case of blockages. Thus flushes off trapped dirt. This reduces the risk of clogging and minimizes maintenance cost drastically
- Industries Most Compact PC Emitter Emitter remain flushed to the lateral. Does not falls down while recoiling.
- Wide Pressure Compensating Range Pressure regulation range 0.6-4 kg/cm² pressure (8.53 to 56.88 psi)
- Excellent CVm, Manufacturer´s Coefficient of Variation Manufacturing coefficient of variation, CVm <= 5% ensures high field emission uniformity
- Maintain the operating pressure within the pressure regulating range.
- Filtration recommendation 130 micron or less. Actual quality of filtration can be decided by quality of source water.
- Please refer to our “Maintenance Manual″ for more details.
Applications
- For orchards and vineyards, greenhouses, nurseries, landscape etc.
- For areas with harsh topographical conditions.
- For irrigation of pot-plants with extension tube.
- Recommended to use where longer length of lateral is required.
|
